La nuova Patrol Carbon è qui! Una bici con cui potrete trovare il vostro limite in bike park o nell''enduro racing. Geometria SBG con due configurazioni Low and High per la massima versatilità e divertimento.
Caratteristiche principali
REAR TRAVEL: 160mm (Compatible with 170mm)
FRONT TRAVEL: 160mm (Compatible with 170mm single crown fork or dual crown forks)
WHEEL SIZE: 29" Front / 27.5" Rear
SIZES: SM, MD, LG, XL
COLORS: Carbon: Moonshadow, Bonfire Red
Alloy: Blueberry, Raw, Moonshadow, Bonfire Red
FRAME BEARINGS: 2x 6903, 2x 6902, 4x 6802, 2x 3802, 2x 6900
FORK AXLE TO CROWN: 574mm at 160mm
FORK OFFSET: 44mm
REAR SHOCK SIZE: 205mm x 60mm (Compatible with 205mm x 65mm)
SHOCK HARDWARE: Trunnion Mount Top / 30mm x 8mm Bottom
HEADSET (TOP): 56mm Zero Stack
HEADSET (BOTTOM): 56mm Zero Stack
BB SHELL: 73mm BSA Threaded
CHAINLINE: 52mm
REAR BRAKE MOUNT: 180mm Post Mount, Max Rotor Size 223mm
DERAILLEUR HANGER: SRAM UDH
REAR AXLE: Transition Axle For UDH, 12mm x 148mm Spacing
ISCG TABS: ISCG05
SEATPOST DIAMETER: 31.6mm
SEAT CLAMP: Carbon: 37.0mm
Alloy: 34.9mm
MAX SEATPOST: Carbon: Small 220mm | Medium 250mm | Large 290mm | XL 320mm
Alloy: Small 200mm | Medium 230mm | Large 270mm | XL 300mm
MAX CHAINRING SIZE: 34T Standard Single Ring (Based on 52mm Boost Chainline)
MAX TIRE SIZE: 27.5 x 2.6
REAR SHOCK SAG: 160mm/60mm: 16-20mm (27-33%)
170mm/65mm: 18-22mm (28-34%)
| FRAME | Patrol Alloy 160mm |
|---|
| WHEEL SIZE | Mixed |
| REAR SHOCK | Fox Float X Performance Elite (205x60) |
| FORK | Fox Float 38 Performance Elite (160 mm) |
| HEADSET | FSA NO.55R/57 |
| STEM | ANVL Swage (40mm) |
| HANDLEBAR | ANVL Mandrel Alloy 35 |
| GRIPS | ODI Elite Flow |
| SADDLE | SDG Bel Air 3 |
| SEATPOST | OneUp Dropper Post |
| BRAKES | TRP DH-R Evo |
| ROTORS | TRP R1 2.3 (203mm) |
| SHIFTER | SRAM GX Eagle |
| DERAILLEUR | SRAM GX Eagle |
| CASSETTE | SRAM XG 1275 (10-52t) |
| CHAIN | SRAM GX Eagle |
| CRANK | SRAM GX Alloy DUB |
| CHAINGUIDE | OneUp Bash Guide |
| RIMS | RaceFace Aeffect R |
| SPOKES | RaceFace 2.0/1.7/2.0 |
| HUBS | RaceFace Trace 28H |
| TIRE/FRONT | Schwalbe Magic Mary, Super Trail, Soft (2.4) |
| TIRE/REAR | Schwalbe Big Betty, Super Trail, Soft (2.4) |
| INCLUDED | Tubeless Valves & Sealant |
